Item R Ref Description Qty Item ef Description Qty
1 1E49F01011 Screw M5×20 9 14 GB/T5783-86 Bolt M8×30 1
2 EHS350C-01002
Transmission
box cover
1 15 GB/T1099-79 Woodruff key 4×13 2
3 EHS400-02008 V-belt 1 16 EHS350C-01016 Blade Shaft 1
4 EHS400-01009 Nut M10-Left 1 17 EHS350C-01018 Washer 2
5 GB/T97-85 Washer 10 1 18 EHS350C-01019 Rubber Ring 1
6 EHS350C-01011
Belt Pulley
Assembly
1 19 EHS350C-01012
Blade Guard
Assembly
1
7 EHS400-01024 Washer 12 1 20 EHS350C-01014 Lock washer 2
8 GB/T893.2-86 Clip 35 2 21 EHS350C-01015 Round locking nut 1
9 GB/T276-94
Ball bearing
6202
2 22 EHS400-01013C Flange 2
10 EHS350C-01017 Ring 1 23 EHS400-01001 Blade*
11 EHS350C-01009 Bolt M8×30 2 24 EHS400-01011 Washer 1
12 EHS350C-01006 Bearing plate 1 25 EHS400-01010 Hexagon Bolt 1
13 EHS350C-01001
Transmission
Box
1
26 EHS350C-01007 Bolt M8×35 2
56
