Chord DAVE User Manual

Chord Electronics
DAVE | Manual
_
Whilst an IR remote control
is supplied, the front panel of
DAVE is the main user interface
and can entirely control all user-
configurable options, inputs and
volume.
3.1 Getting to know DAVE
3.2 The front panel
3.3 The top panel
3.4 The rear panel
3.5 The remote control
The front panel 3.2
13 // 35
DAVE features a single
headphone output available on
the front of the device. This can
accommodate headphones up
to 800 Ω without the need for an
additional headphone amplifier.
LCD screen
Volume dial and
confirmation button
IR remote control
receiver window
Cycle through menu
options
6.35mm headphone jack
Cycle through menu
options
Down through
menu
Up through
menu

Chord DAVE Specifications

Audio Specifications

frequency response	20Hz to 20kHz
THD + N	127.5dB
channel separation	>125dB @ 1KHz
dynamic range	127.5dB

Digital Inputs and Outputs

digital inputs	4 x 75Ω SP/DIF BNC Coax 44.1KHz - 384KHz
AES balanced XLR input	44.1KHz - 96KHz
plastic fibre optic inputs	2 x TOSlink 44KHz - 192KHz
USB input	44KHz - 768KHz PCM + DSD
analogue outputs	2 x RCA Phono, 2 x Balanced XLR
headphone output at 300 ohm	1% THD 6.8v RMS (154 mW)
headphone output at 33 ohm	1% THD 6.8v RMS (1.4W)

Power and Dimensions

power supply	90V AC - 250V AC auto switching 50 - 60HZ
dimensions	338 x 60 x 145mm (Width x Height x Depth)
weight	7Kg
