Chord DAVE User Manual

Chord Electronics
DAVE | Manual
_
For convenience, a branded
infra-red remote control is
included with DAVE.
The remote will operate up to a
distance of 10 metres (with clear
line-of-sight) to the infra-red
receiver within DAVE, which is
located above the LCD screen.
For best operation, do not
operate DAVE within a cabinet or
place other materials/products
on top of the device.
3.1 Getting to know DAVE
3.2 The front panel
3.3 The top panel
3.4 The rear panel
3.5 The remote control
The remote control 3.5
15 // 35
NOTE: Please only
insert AAA batteries
into the IR remote
control and observe the
correct orientation as
indicated. Failure to do so
could result in non-operation
or battery leakage.
Menu
Mute
Vol+
Vol -
On/o
Activate menu
Cycle through inputs and
menu
Mute playback
Decrease volume
Cycle though inputs and
menu
Increase volume

Chord DAVE Specifications

Audio Specifications

frequency response	20Hz to 20kHz
THD + N	127.5dB
channel separation	>125dB @ 1KHz
dynamic range	127.5dB

Digital Inputs and Outputs

digital inputs	4 x 75Ω SP/DIF BNC Coax 44.1KHz - 384KHz
AES balanced XLR input	44.1KHz - 96KHz
plastic fibre optic inputs	2 x TOSlink 44KHz - 192KHz
USB input	44KHz - 768KHz PCM + DSD
analogue outputs	2 x RCA Phono, 2 x Balanced XLR
headphone output at 300 ohm	1% THD 6.8v RMS (154 mW)
headphone output at 33 ohm	1% THD 6.8v RMS (1.4W)

Power and Dimensions

power supply	90V AC - 250V AC auto switching 50 - 60HZ
dimensions	338 x 60 x 145mm (Width x Height x Depth)
weight	7Kg
