Chord Mojo User Manual

Product Specification
HARMONIC DISTORTION < -103dB
SIGNAL TO NOISE RATIO >120dB
CHANNEL SEPARATION >125dB @ 1KHz
DYNAMIC RANGE 122dB
DIGITAL INPUTS 1 x 75Ω SPDIF 3.5mm 44.1KHz - 384KHz
1 x Plastic fibre optic ( TOSlink ) 44KHz - 192KHz,
1 x USB 44KHz – 768KHz
HEADPHONE OUTPUTS 2 x 3.5mm Jack Sockets
OUTPUT IMPEDANCE 75mohm (short circuit protected)
- ! -8

Chord Mojo Specifications

General

Output impedance	0, 075 Ω
Adjustable volume	Yes
Peak power per channel	0.72 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	0.00017 %
Audio (L/R) in	1
Headphone connectivity	3.5mm
USB 2.0 ports quantity	2
Power source	Battery
Product color	Black
LED indicators	Power, USB

Weight and Dimensions

Depth	82 mm
Width	60 mm
Height	22 mm
Weight	180 g
