Chris-Craft Technical Drawings
Figure 7. Lancer 22 – Helm Breaker Panel
LANCER 22 HELM BREAKER PANEL
BREAKER SIZE BREAKER SIZE BREAKER SIZE
IGNITION 10 AMPS BILGE PUMP 5 AMPS NAVIGATION LT 5 AMPS
BLOWER 10 AMPS ACC SWITCH (RUMBLE) 10 AMPS COCKPIT LTS 5 AMPS
EXHAUST (OPTION) 5 AMPS ACCESSOR (RUMBLE) 25 AMPS HORN 5 AMPS
WATER PUMP (OPT) 10 AMPS TRIM TABS 20 AMPS 12V OUTLET 15 AMPS
To Next Page
