3–4 Chris-Craft
Systems
Engine Compartment
The engine compartment normally contains the following components:
•Engine(s)
• Batteries
• Trim Tab Pump (if installed)
•Engine Trim Pump
•Bilge Pump
Other components may be included within the engine compartment depending upon the model of boat and
options chosen.
The engine compartment is accessed via the engine hatch located at the stern of the boat. All models except
the Lancer 20, Lancer 22 Rumble, and Launch 22 utilize either a single or dual electric power lift which is
activated from the helm (Figure 3-2). Actual location of this switch may vary from model to model.
The Lancer 20, Lancer 22 Rumble, and Launch 22 employs a manual latch release mechanism which uti-
lizes a gas assisted piston to lift the engine hatch.
Figure 3-2. Engine Hatch Activation Switch
