Chris-Craft Technical Drawings
Figure 10. Lancer 22 – Battery Switch Panel
LANCER 22 BATTERY SWITCH PANEL
BREAKER
BATTERY SWITCH
SIZE BREAKER SIZE
5 AMPS
10 AMPS
AMPLIFIER 15 AMPS
MAIN 40 AMPS
