Programmable DC Electronic Load 6310 Series Operation & Programming Manual
MODEL 63301 63305
POWER
20W 200W 30W 300W
CURRENT
0∼4A 0∼40A 0∼1A 0∼10A
VOLTAGE
1∼80V 2.5∼500V
MIN. OPERATING VOLTAGE (DC)
1.0V at 4A 1.0V at 40A 2.5V at 1A 2.5V at 10A
CONSTANT CURRENT MODE
Range
0∼4A 0∼40A 0∼1A 0∼10A
Resolution
1mA 10mA 0.25mA 2.5mA
Accuracy
0.1%+0.1%F.S. 0.1%+0.2%F.S. 0.1%+0.1%F.S. 0.1%+0.2%F.S.
CONSTANT RESISTANCE MODE
Range
0.0375Ω∼150Ω (200W/16V)
1.875Ω∼7.5KΩ (200W/16~80V)
1.25Ω∼5KΩ (300W/125V)
50Ω∼200KΩ (300W/125~500V)
Resolution
12 bits 12 bits
Accuracy
150Ω : 0.1 mho +0.2%
7.5KΩ : 0.01
mho +0.1%
5KΩ : 20m
mho +0.2%
200KΩ : 5m
mho +0.1%
CONSTANT VOLTAGE MODE
Range
1∼80V 2.5∼500V
Resolution
20mV 125mV
Accuracy
0.05%±0.1%F.S. 0.05%±0.1%F.S.
DYNAMIC MODE
DYNAMIC MODE
C.C. MODE C.C. MODE
T1 & T2 0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
Accuracy
1μS /1mS+100ppm 1μS /1mS+100ppm
Slew Rate
0.64∼160mA/μS6.4∼1600mA/μS0.16∼40mA/μS 1.6∼400mA/μS
Resolution
0.64mA/μS 6.4mA/μS 0.16mA/μS 1.6mA/μS
Current
0∼4A 0∼40A 0∼1A 0∼10A
Resolution 1mA 10mA 0.25mA 2.5mA
Current Accuracy 0.4% F.S. 0.4% F.S.
MEASUREMENT SECTION
VOLTAGE READ BACK
Range
0∼16V 0∼80V 0∼125V 0∼500V
Resolution 0.5mV 2.5mV 4mV 16mV
Accuracy 0.05%+0.05% F.S. 0.05%+0.05% F.S.
CURRENT READ BACK
Range
0∼4A 0∼40A 0∼1A 0∼10A
Resolution 0.125mA 1.25mA 4mA 16mA
Accuracy 0.1%+0.1% F.S. 0.1%+0.1% F.S.
PROTECTIVE SECTION
Over Power Protection
≒20.8W ≒208W ≒31.2W ≒312W
Over Current Protection
≒4.08A ≒40.8A ≒1.02A ≒10.2A
Over Temperature Protection
≒85°C ≒85°C
Over Voltage Protection
≒81.6V ≒510V
GENERAL
SHORT CIRCUIT
Current (CC) -
≒40A
-
≒10A
Voltage (CV) - 0V - 0V
Resistance (CR) -
≒0.0375Ω
-
≒1.25Ω
INPUT RESISTANCE
(LOAD OFF)
100KΩ (Typical) 100KΩ (Typical)
SIZE
81(W)× 172(H)×495(D) 81(W)× 172(H)×495(D)
WEIGHT (Approx.)
4.2Kg 4.2Kg
EMC & SAFETY
CE CE
1-4
