General Information
MODEL 63302(100W*2) 63303
POWER
20W 100W 30W 300W
CURRENT
0∼2A 0∼20A 0∼6A 0∼60A
VOLTAGE
1∼80V 1∼80V
MIN. OPERATING VOLTAGE (DC)
1.0V at 2A 1.0V at 20A 1.0V at 6A 1.0V at 60A
CONSTANT CURRENT MODE
Range
0∼2A 0∼20A 0∼6A 0∼60A
Resolution
0.5mA 5mA 1.5mA 15mA
Accuracy
0.1%+0.1%F.S. 0.1%+0.2%F.S. 0.1%+0.1%F.S. 0.1%+0.2%F.S.
CONSTANT RESISTANCE MODE
Range
0.075Ω∼300Ω (100W/16V)
3.75Ω∼15KΩ (100W/16~80V)
0.025Ω∼100Ω (300W/16V)
1.25Ω∼5KΩ (300W/16~80V)
Resolution
12 bits 12 bits
Accuracy
300Ω : 0.1 mho +0.2%
15KΩ : 0.01
mho +0.1%
100Ω : 0.1
mho +0.2%
5KΩ : 0.01
mho +0.1%
CONSTANT VOLTAGE MODE
Range
1∼80V 1∼80V
Resolution
20mV 20mV
Accuracy
0.05%±0.1%F.S. 0.05%±0.1%F.S.
DYNAMIC MODE
DYNAMIC MODE
C.C. MODE C.C. MODE
T1 & T2
0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
Accuracy
1μS /1mS+100ppm 1μS /1mS+100ppm
Slew Rate
0.32∼80mA/μS3.2∼800mA/μS 0.001∼0.25A/μS 0.01∼2.5A/μS
Resolution
0.32mA/μS3.2mA/μS 0.001A/μS 0.01A/μS
Current
0∼2A 0∼20A 0∼6A 0∼60A
Resolution
0.5mA 5mA 1.5mA 15mA
Current Accuracy
0.4% F.S. 0.4% F.S.
MEASUREMENT SECTION
VOLTAGE READ BACK
Range
0∼16V 0∼80V 0∼16V 0∼80V
Resolution
0.5mV 2.5mV 0.5mV 2.5mV
Accuracy
0.05%+0.05% F.S. 0.05%+0.05% F.S.
CURRENT READ BACK
Range
0∼2A 0∼20A 0∼6A 0∼60A
Resolution
0.0625mA 0.625mA 0.1875mA 1.875mA
Accuracy
0.1%+0.1% F.S. 0.1%+0.1% F.S.
PROTECTIVE SECTION
Over Power Protection
≒20.8W ≒104W ≒31.2W ≒312W
Over Current Protection
≒2.04A ≒20.4A ≒6.12A ≒61.2A
Over Temperature Protection
≒85°C ≒85°C
Over Voltage Protection
≒81.6V ≒81.6V
GENERAL
SHORT CIRCUIT
Current (CC)
-
≒20A
-
≒60A
Voltage (CV)
- 0V - 0V
Resistance (CR)
-
≒0.075Ω
-
≒0.025Ω
INPUT RESISTANCE (LOAD OFF)
100KΩ (Typical) 100KΩ (Typical)
SIZE
81(W)× 172(H)×495(D) 81(W)× 172(H)×495(D)
WEIGHT (Approx.)
4.2Kg 4.2Kg
EMC & SAFETY
CE CE
