8. Specifications
Control Modes
ON/OFF; PI—Proportional with integral
Control Adjustments
Proportional Band 1 to sensor span maximum
Automatic Reset 0.0 to 100.0 repeats/minute
Cycle Time 0.1 to 60.0 seconds
On/Off Deadband 1° to 100°F or °C
Set Point Upper Limit sensor range °F or °C
Set Point Lower Limit sensor range °F or °C
Output Limit 0 to 100%
Alarm Adjustments
Type Absolute High or Low
Set Point Sensor range °F or °C
Alarm Dead Band 0° to 100°F or °C
Control/Alarm Outputs
Relay (R1) 1 Amp Form A, 120/240VAC
Relay (R3) Form A, 120/240VAC resistive loads at 30 sec. cycle time
20 Amps, 500,000 Operations
15 Amps, 1 Million Operations
10 Amps, 5 Million Operations
5 Amps, 5 Million Operations
Solid State Relay Drive (V0) 24VDC at 40mA
Solid State Relay (S0) 1A Triac, up to 240VAC
Solid State Relay (S1) 5A, up to 240VAC at 40°C
Solid State Relay (S2) 10A, up to 240VAC at 40°C
Alarm Form C, Relay 5 Amps at 120VAC, 2.5A at 240VAC
Sensor Input
Switch selectable; J,K Thermocouple; RTD
Input Update Rate
Four samples per second
Input Specifications
Range °F Range °C
Accuracy at 77°F ambient
J TC -100 to 1400°F -73 to 760°C
0.2% Span +/-1 least significant digit
K TC -100 to 2400°F -73 to 1316°C
0.2% Span +/-1 least significant digit
100W Pt RTD (a=.00385) -200 to 1000°F -128 to 538°C
0.2% Span +/-1 least significant digit
Readout Stability
J and K TC +/-1°F per 10°F change in ambient temperature
RTD +/-0.5°F per 10°F change in ambient temperature
Open Sensor and Out-of-Range
Conditions
Displays “SEnS”, Control output 0%
Instrument Power
90 to 260VAC Less than 10 VA
Operating Environment
0° to 65°C (32° to 150°F)
Dimensions
Overall 4.0 x 4.0 x 4.0 inches (102 mm)
Depth Behind Display. 3.6 inches (92 mm)
Front Panel Projection 0.4 inches (10 mm)
Panel Cutout 3.6 x 3.6 inches (92 mm x 92 mm)
Enclosure Material
High temp ABS plastic rated for 0° to 175°F
