3
Model Identification
Before installation, please identify your controller mod-
el number. The model number appears on a label on
the side of the housing.
Use Figure 2.3 to identify the options in your controller.
Model
2110 1/4 DIN Controller, with Selectable Thermocouple or RTD Inputs
Code Control Output
R1 Relay, 1 Amp Form A, 120/240Vac
R3 Relay, 20 Amps Form A, 120/240Vac
V0 Solid State Relay Drive, 24Vdc @ 40ma
S0 Solid State Relay, 1 Amp, up to 240 Vac
S1 Solid State Relay, 5 Amps, up to 240Vac
S2 Solid State Relay, 10 Amps, up to 240Vac
Code Alarm Output (Kit Option)
0 No Alarm
1 Alarm Form “C” Relay, 5 Amps at 120Vac, 2.5 Amps at 240Vac
Code
0 Add to Complete Part Number
Code Power Supply
0 90-260Vac
2110 - R3 1 0 0 Typical Model Number
Figure 2.3 Model Identification
