Linear DC:
Resolution: Eight bits in 250mS
(10 bits in 1 second typical, >10 bits in >1
second typical).
Update Rate: Every control algorithm execution.
Ranges: 0 to 10V
0 to 5V
2 to 10V 0 to 20mA
4 to 20mA (default)
Load Impedance: 0 to 20mA & 4 to 20mA:
500Ω maximum.
0 to 5V, 0 to 10V & 2 to 10V:
500Ω minimum.
Short circuit protected.
Accuracy: ±0.25% (mA @ 250Ω, V @ 2kΩ).
Degrades linearly to ±0.5% for increasing
burden (to specification limits).
When used as control
output:
For 4 to 20mA and 2 to 10V a 2% over/
under-drive is applied (3.68 to 20.32mA and
1.84 to 10.16V).
Isolation: Reinforced safety isolation from inputs and
other outputs.
Use as 0 to 10VDC
transmitter power supply*
Indicators only.
Adjustable, 0.0 to 10.0V (regulated) output
into 500Ω minimum.
Transmitter Power Supply:
*see Linear output spec
for 0-10V PSU
Power Rating 19 to 28VDC (24V nominal) into 910Ω
minimum resistance.
Isolation: Reinforced safety isolation from inputs and
other outputs.
Control Specifications
Automatic Tuning Types:
Pre-Tune, Self-Tune.
Proportional Bands:
0 (ON/OFF control), 0.5% to 999.9% of input span at 0.1% increments.
ON/OFF control not valid for VMD controllers.
Automatic Reset (Integral Time
Constant):
1s to 99min 59s and OFF.
Rate (Derivative Time Constant):
0 (OFF) to 99 min 59 s.
Manual Reset (Bias):
Added each control algorithm execution. Adjustable in the range 0 to
100% of output power (single output) or -100% to +100% of output
power (dual output). Not valid for VMD controllers.
Deadband/Overlap:
-20% to +20% of Proportional Band 1 + Proportional Band 2.
Not valid for VMD controllers
ON/OFF Differential:
0.1% to 10.0% of input span.
Motor Travel Time
5 seconds to 5 minutes
Minimum Motor On Time
0.0 seconds to (Motor Travel Time/10)
MAN/AUTO Control:
User-selectable with “bumpless” transfer into and out of Manual Control.
Cycle Times:
Selectable from 0.5s to 512 seconds in binary steps.
Setpoint Range:
Limited by Setpoint Upper Limit and Setpoint Lower Limit.
Setpoint Maximum:
Limited by Setpoint and Scale Range Upper Limit.
Setpoint Minimum:
Limited by Scale Range Lower Limit and Setpoint.
Setpoint Ramp:
Ramp rate selectable 1 to 9999 LSD’s per hour and infinite.
Number displayed is decimal-point-aligned with display.
