(c) Slide the solenoid straight off the shift lever
mounting stud.
(28) If the vehicle is equipped with a steering col-
umn mounted shift lever, remove the shift cable from
the shifter mechanism. Unlock the cable lock, then,
the shift cable is removed by inserting a screwdriver
between the shift cable and the shifter mechanism
and prying the cable off the pin (Fig. 23).
(29) Remove the shift cable mounting bracket (Fig.
24) from the steering column. The shift cable mount-
ing bracket is mounted to the steering column by the
2 mounting screws (Fig. 24).
Fig. 21 BTSI Solenoid
1 – SHIFT LEVER BRACKET
2 – SOLENOID
3 – KEY CYLINDER
Fig. 22 Solenoid Retainer Clip Removal
1 – SOLENOID
2 – MOUNTING STUD
3 – RETAINER CLIP
Fig. 23 Shift Cable Removal
1 – STEERING COLUMN
2 – SCREWDRIVER
3 – PIN
4 – SHIFT CABLE
5 – SHIFTER MECHANISM
Fig. 24 Shift Cable Bracket Mounting To Steering
Column
1 – STEERING COLUMN
2 – SHIFT CABLE
3 – SHIFT CABLE MOUNTING BRACKET
4 – MOUNTING SCREWS
LH STEERING 19 - 53
REMOVAL AND INSTALLATION (Continued)
To Next Page
