ASSEMBLY
(1) Install valves and springs as shown in (Fig.
137).
(2) Install regulator valve spring retainer (Fig.
138).
(3) Install dual retainer plate using Tool 6301 (Fig.
139).
(4) Install vent reservoir check valve and spring
(Fig. 140).
(5) Install the vent reservoir check valve retainer
(Fig. 141).
(6) Verify that all retainers are installed as shown
in (Fig. 142). Retainers should be flush or below
valve body surface.
(7) Install 2/4 Accumulator components as shown
in (Fig. 143). Torque 2/4 Accumulator retainer plate
to 5 N·m (45 in. lbs.).
(8) Install check balls into position as shown in
(Fig. 144). If necessary, secure them with petrolatum
or transmission assembly gel for assembly ease.
Fig. 138 Install Regulator Valve Spring Retainer
using Tool 6302
1 – TOOL 6302
2 – RETAINER
Fig. 139 Install Dual Retainer Plate using Tool 6301
1 – TOOL 6301
2 – RETAINER
Fig. 140 Vent Reservoir Check Valve and Spring
1 – RETAINER
2 – SPRING
3 – BALL
Fig. 141 Install Vent Reservoir Check Valve Retainer
1 – RETAINER
