CAUTION: Tag the springs for the Overdrive Accu-
mulator so that they are not confused with the
springs in the Low/Reverse Accumulator.
Fig. 161 Remove Underdrive Accumulator and
Spring
1 – ACCUMULATOR PISTON (UNDERDRIVE)
2 – RETURN SPRINGS
3 – SEAL RING
4 – SEAL RING
Fig. 162 Remove Overdrive Accumulator and
Springs
1 – OVERDRIVE ACCUMULATOR PISTON
2 – RETURN SPRINGS
3 – SEAL RING
4 – SEAL RING
Fig. 163 Accumulator Locations
1 – OVERDRIVE ACCUMULATOR LOCATION
2 – UNDERDRIVE ACCUMULATOR LOCATION
3 – LOW/REVERSE ACCUMULATOR
Fig. 164 Remove Low/Reverse Accumulator
1 – SNAP RING
2 – LOW/REVERSE ACCUMULATOR
21 - 68 42LE TRANSAXLE LH
DISASSEMBLY AND ASSEMBLY (Continued)
