Chrysler Concorde - Page 1238

NOTE: Remove driveshaft retainer clips from drive-
shafts.
Fig. 165 Remove Low/Reverse Accumulator Plug
(Cover)
1 – ADJUSTABLE PLIERS
2 – PLUG
Fig. 166 Remove Low/Reverse Accumulator Piston
1 – SEAL RINGS
2 – PISTON
3 – PISTON
4 – PETROLATUM
5 – SUITABLE TOOL
Fig. 167 Low/Reverse Accumulator
1 – ACCUMULATOR PISTON
2 – SEAL RINGS
3 – RETURN SPRINGS
4 – (NOTE NOTCH)
Fig. 168 Remove Long Stub Shaft Snap Ring
1 – SNAP RING
2 – SNAP RING PLIERS
3 – LONG STUB SHAFT
LH 42LE TRANSAXLE 21 - 69
DISASSEMBLY AND ASSEMBLY (Continued)
