Fig. 189 Remove Tapered Snap Ring
1 – LOW/REVERSE CLUTCH REACTION PLATE
2 – LONG TAB
3 – SCREWDRIVER
4 – LOW/REVERSE TAPERED SNAP RING (TAPERED SIDE UP)
5 – OIL PAN FACE
Fig. 190 Remove One Disc
1 – ONE DISC FROM LOW/REVERSE CLUTCH
Fig. 191 Remove Low/Reverse Reaction Plate Snap
Ring
1 – SCREWDRIVER
2 – LOW/REVERSE REACTION PLATE FLAT SNAP RING
3 – DO NOT SCRATCH CLUTCH PLATE
Fig. 192 Remove Low/Reverse Clutch Pack
1 – CLUTCH PLATES (5)
2 – CLUTCH DISCS (5)
LH 42LE TRANSAXLE 21 - 75
DISASSEMBLY AND ASSEMBLY (Continued)
