Exploded view & dismantling sequence of parts
- 27 -
2. Exploded view schedule of indoor unit of FR(D)180/S and FR(D)260/S
No. Description Remark
1 Top plate assembly
2 Strainer I
3 Evaporator assembly
4 Strainer 2
5 Water tray assembly
6 Strainer retaining strip
7 Left side plate assembly
8 Fixing block
9 Left small hole cover plate
10 Square hole cover plate assembly
11 Air intake
12 Bottom plate assembly
13 Impeller
14 Spiral casing assembly
15 Tapping screw ST4X12
16 Front panel assembly
17 Motor
18 Bolt M6X16
19 Motor fixing block
20 Capacitor clip
21 Capacitor
22 Right side plate assembly
23 Right small hole cover plate assembly
24 Mounting strip
25 Bolt with two washers
26 Retainer
