CHUNLAN -B - Chapter VIII Installation; Installation Schematic

List of main parts & wear parts
- 64 -
Size/Model
Symbol Description
FR(D)180/S FR(D)260/S
T Transformer Z371 ------
FU Fuse 10A 10A
FU3 Fuse AC380 2A ------
YV Reversing solenoid valve STF-0408 STF-0714
KM AC contactor 3TF34 3TF34
Valve Dg10 ------
Valve Dg19 ------
Axial flow fan RF180W/S.000.01WX ------
Impeller RF10A/FG.062.00 ------
8. List of special main parts/wear parts for FRD180/S & FRD260/S aux. electric heating
Size/Model
Symbol Description
FRD180/s FRD260/S
PCB1 Main control board ------ ------
FT
1,2,3,4,5,6
1-time fuse
153℃ 10A 153℃ 10A
KT
1,2,3,4,5,6
Auto-reset thermal protector
KSD-A135℃ 10A KSD-A135℃ 10A
EH
1,2,3,4,5,6
PTC heater MZFR 1KW MZFR 1.5KW
XT1 Wiring terminal JXO-AB(600V 60A) JXO-AB (600V 60A)
XT4 Wiring terminal JXW-Z
11
-03 JXW-Z
11
-03
XT5 Wiring terminal JXW-Z
11
-03 JXW-Z
11
-03
KM1 AC contactor 3TF3000 3TF3200
