Installation Manual Page 38 of 51 Sioux Pro 2
Note: For optimum operation of the serial line LINE3, is recommended to set as factory default.
SET LINE3
LINE3 Termination settings
DIP1
DIP2
DIP3
OFF
OFF
OFF
Line not terminated and not polarised
ON
ON
OFF
Line polarised and not terminated
OFF
OFF
ON
Line terminated and not polarised
ON
ON
ON
Line terminated and polarised
LINE3
Description
VCC
Power supply output:13.8 V
GND
Ground
LH
RS485 High Line
LO
RS485 Low Line
SHLD
Shield
TAMPER
Description
TAMP
Tamper input
GND
Ground
POWER
Description
VCC
Power supply: 13.8 V
GND
Ground
MAIN FAULT
Main power presence (+13,8 Vdc)
SHLD
Shield
NB: If you use only the Sioux-CU-Pro2, the connection between the unit and the power supply
must be realized with a correct section cable (1,5mm² at least). The cable must be shielded type,
with shield connected to ground.
