CONDENCIAT CD D
350
50x350
400
500
450
600
700
9 - FLOOR MOUNTING
Top view of FRAME Top view of FRAME
Size 100 to 300 V Size 350 to 700 V
Hydraulic
module Size
180 to 300
CD L1 L2 L3 L4
100 - 300 316 316 1540 1044
350 - 500 281 281 2185 2123
540 - 700 405 281 2735 2123
The frame may be bolted to the ground (bolts not supplied by CIAT). The hardness is to be dened depending on the weight and
centre of gravity of the unit.
