TRANSMIG 350i, 450i, 550i
Manual 0-5205 3-19 INSTALLATION, OPERATION AND SETUP
Negative Welding
Terminal (-)
Work Lead
Mig Torch
Powered Wirefeeder (19 Pin)
Positive Welding
Terminal (+)
19 Pin Control Socket
A-10639
Figure 3-7: Setup for Mig Welding with Gas Shielded Mig Wire
