Cillit Access 10 - Cillit Access 15; 15 Bio; Cillit Access 20; 20 Bio

21
EN
20
EN
7.3 Cillit
®
Access 20 / 20 Bio*
Cillit
®
Access Unit 20 / 20 Bio
Nominal connection (outside thread) BSP ¾“ (DN 20)
Nominal ow rate in accordance with EN 14743 l/h 1680
Operating pressure EU (min./max.) bar 1.0 / 8.0
Operating pressure UK (min./max.) bar 1.7 / 5.0
Pressure drop down at nominal ow in accordance
with EN 14743
bar 1.0
Quantity of ion exchange resin l 20
Nominal capacity (EN 14743) / (CaCO3 mmol/l) m³x°dH/mol/ppm 60 / 10.7 / 1070
Capacity salt reservoir kg 24
Salt consumption per regeneration kg 2.5
Water consumption per regeneration l 125
Protection class IP 51
Water temperature (min./max.) °C 5 / 30
Ambient temperature (min./max.) °C 5 / 40
Electrical connection V / Hz 230 / 50
Dimensions: Width x depth x height (W x D2 x H) mm 270 x 480 x 804
Connection height (A) / overow height (S) mm 675 / 540
Operating weight, approx. kg 65
*Tested with HiFlow connection available in option
7.2 Cillit
®
Access 15 / 15 Bio*
Cillit
®
Access Unit 15 / 15 Bio
Nominal connection (outside thread) BSP ¾“ (DN 20)
Nominal ow rate in accordance with EN 14743 l/h 1560
Operating pressure EU (min./max.) bar 1.0 / 8.0
Operating pressure UK (min./max.) bar 1.7 / 5.0
Pressure drop down at nominal ow in accordance
with EN 14743
bar 1.0
Quantity of ion exchange resin l 15
Nominal capacity (EN 14743) / (CaCO3 mmol/l) m³x°dH/mol/ppm 43 / 7.7 / 770
Capacity salt reservoir kg 16
Salt consumption per regeneration kg 2.0
Water consumption per regeneration l 105
Protection class IP 51
Water temperature (min./max.) °C 5 / 30
Ambient temperature (min./max.) °C 5 / 40
Electrical connection V / Hz 230 / 50
Dimensions: Width x depth x height (W x D2 x H) mm 270 x 480 x 602
Connection height (A) / overow height (S) mm 473 / 350
Operating weight, approx. kg 50
*Tested with HiFlow connection available in option
W
H
D
1
D
2
A
S
W
D
1
D
2
H
A
S
