MA4 Spare Parts Kit Part #302-178-000
MA4 Melter Applicator Service Parts Kits (Optional)
1
# PART # DESCRIPTION QTY. # PART # DESCRIPTION QTY.
1 153621 Pump Thermocouple Bent 1 7 403527 Tool Box Assembly 1
2 156287 Spray Tip, 1/2 NPT 95-50 5 8 172675 4FJ Cap 304-C-4 1
3 156286 Gasket, Applicator Valve 5 9 172XXX 4 MB Plug MORB-STR 1
4 111904 Sprocket, No. 35 11 Tooth 1 10 172674 4 MB Plug Hex Head 6408-4 1
5 156285 Poppet, Spray Valve 1 11 172673 O-Ring .875 8
6 101245 Roll Pin / Spring .06 x 1.00 5 12 172664 Cylinder Application Tip 1
M-Series Melter Spare Parts Kit Part #404695
1
2
7
8
3
4
6
# PART # DESCRIPTION QTY. # PART # DESCRIPTION QTY.
1 152105 Electric Eye 1 5 130384 Material Controller 1
2 200352 Burner Primary Control 1 6 130097 Thermocouple 2
3 130113 12V/30A Relay (Hose & Burner) 1 7 130505 240V/18A Ceramic Fuse 1
4 152399 Burner Coupling 1 8 152883 12V/10A Blade Fuse (Qty 5) 5
