CIMLINE MA4 - MA4 Agitation System Parts

58
# PART # DESCRIPTION QTY. # PART # DESCRIPTION QTY.
1 404327 Motor Mount 1 11 100126 Washer - Flat .38 9
2 170602 Motor - 45 CU IN 1 12 100093 Washer - Split-lock .38 9
3 111087 Sprocket 1 13 110294 Key .38 X 2.00 LG 1
4 111088 Sprocket 1 14 100006 HHCS .31 X 1.0 2
5 420169 Plate - Agitator 1 15 100069 Nut - Hex .38 1
6 420171 Adjustment Angle 1 16 100015 Bolt, Hex 3/8-16 X 3/4 8
7 171173 Load Adapter 1 17 100092 Washer - Split-lock .31 2
8 100095 Washer - Split-lock 1/2" 2 18 110488 Chain No. 50 X 68 Links 1
9 100039 HHCS 1/2 X 3-1/2 2 19 110190 Link - Master No. 50 1
10 100295 HHCS 3/8 X 3 FL THD 1
PART # DESCRIPTION
153772 Seal Kit for Hydraulic Motor
MAINTENANCE KIT:
MA4 Agitation System Parts
