45
COMPLETE ASSEMBLY (ITEMS 1-11) - Part #404518
Combustion Chamber Parts
# PART # DESCRIPTION QTY.
1 403400 Chamber Lining Kit 1
2 402898 Burner Mount 1
3 402893 Heat Chamber Skin 1
4 417041 Inspection Cover 1
5 152487 Insulation Heat Chamber 1
6 100125 Washer-Flat .31 16
7 100093 Washer - Split Lock .38 2
8 100092 Washer - Split Lock .31 8
9 100068 Nut - Hex .31 8
10 100015 Bolt - Hex 3/8 - 16 X 3/4 2
11 100006 HHCS .31 X 1.0 8
