CipherLab 8630 User Manual

73
Appendix III 2D Scan Engine
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
Any Length
GS1 DataBar (RSS) ---
GS1 Databar-14 GS1 DataBar-
14 is short for GS1 DataBar Omnidirectional.
This group consists of (1) GS1 DataBar Omnidirectional,
(2) GS1 DataBar Truncated, (3) GS1 DataBar Stacked, and
(4) GS1 DataBar Stacked Omnidirectional.
Enable
GS1 Databar Limited Enable
GS1 Databar Expanded
This group consists of (1) GS1 DataBar Expanded, and (2)
GS1 DataBar Expanded Stacked.
Enable
Conv
ert RSS to
UPC/EAN
"Convert to UPC/EAN" only applies to GS1 Databar-
14 and
GS1 Databar
Limited barcodes not decoded as part of a
Composite barcode.
Convert to EAN-13
Strip the leading "010" from barcodes.

"01" is the Application ID and must be followed by a
single zero (the first digit encoded)
Convert to UPC-A
Strip the leading "0100" from barcodes.

"01" is the Application ID and must be followed by
two or more zeros (but not six zeros)
No
EAN-8 Enable
Convert to EAN-13 The EAN-8 barcode will be expanded into EAN-
13, and the
next processing will follow the settings configured for
EAN-13.
No
Addon 2 / Addon 5 Refer to UPC/EAN Addon setting.
EAN-13 Enable
Bookland EAN (ISBN) The EAN-
13 barcode starting with 978 will be converted to
ISBN.
No
Addon 2 / Addon 5 Refer to UPC/EAN Addon setting.
UPC-A Enable
Transmit Check Digit Decide whether to include the UPC-A check digit
in the
data being transmitted.
Yes
Transmit Preamble Decide whether to include the UPC-
A preamble System
Number (and Country Code) in the data being transmitted.
System
Number
Addon 2 / Addon 5 Refer to UPC/EAN Addon setting.
UPC-E0 Enable
Transmit Check Digit Decide whether to include the UPC-E0 check digit
in the
data being transmitted.
Yes
Transmit Preamble Decide whether to include the UPC-
E0 preamble System
Number (and Country Code) in the data being transmitted.
System
Number
