URBAN DC
28
Installation Guide
7
MODELS SPECIFICATIONS
Models URBAN DC MASTER, URBAN DC SATELLITE, URBAN DC BASIC
Maximum AC input current 39A
Required power supply capacity 27 kVA
Maximum output power 25 kW
Output voltage range 150-920 Vdc
Maximum output current 70 A
Number of connectors 1
Connector type
CCS 2
L
GENERAL DATA
Light beacon RGB Colour indicator
ELECTRICAL DATA
AC Power supply 3P+N+PE
AC Input Voltage 400 V ± 10% (Three-phase)
Power factor > 0.98
Efficiency 94 % at nominal output power
Frecuency 50/60 Hz
Charging protocols CCS2
Safety Protections
RCD type B (30 mA)
MCB (curve C)
MODEL URBAN DC SATELLITE
Master Communication Ethernet UTP
