Power supply (one LED for each power supply):
• Off—No AC input (12-V main power off;
12-V standby power off)
• Green, flashing—12-V main power off; 12-V
standby power on.
• Green—12-V main power on; 12-V standby
power on.
• Amber, flashing—Warning threshold
detected but 12-V main power on.
• Amber—Critical error detected; 12-V main
power off ( for example, overcurrent,
overvoltage, or overtemperature failure).
6Unit identification:
• Off—The unit identification function is not
in use.
• Blue, flashing—The unit identification
function is activated.
5
Power Supply
The following table lists the specifications for each 770-W AC power supply used in the FMC 1600, 2600,
and 4600.
Table 2: Power Supply Specifications
SpecificationDescription
1313 BTU/hrPower consumption
Nominal range: 100 to 120 V AC, 200 to 240 V AC
Range: 90–132 V AC, 180–264 V AC
AC input voltage range
Nominal range: 50–60 Hz
Range: 47–63 Hz
AC input frequency
9.5 A peak at 100-V AC
4.5 A peak at 208 V AC
Maximum AC input current
950 VA at 100 V ACMaximum input volt amperes
770 WMaximum output power for each power supply
15 A (subcycle duration)Maximum inrush current
12 ms at 770 WMaximum hold-up time
12 V DCPower supply output voltage
12 V DCPower supply standby voltage
Climate Savers Platinum Efficiency (80 Plus Platinum
certified)
Efficiency rating
Cisco Firepower Management Center 1600, 2600, and 4600 Hardware Installation Guide
14
