Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Overview of the Hardware and Software
New Slots and Ports by Platform
New Slots and Ports by Platform
This section provides the type and number of the slots and ports available in the Cisco 3900 series,
2900 series, and 1900 series ISRs.
• Cisco 3900 Series ISRs, page 5
• Cisco 2900 Series ISRs, page 5
• Cisco 1900 Series ISRs, page 6
Cisco 3900 Series ISRs
Table 4 lists the slots and ports available on Cisco 3900 series routers.
To view the installation guide, see the following URL
http://www.cisco.com/en/US/docs/routers/access/2900/hardware/installation/guide/Hardware_Installati
on_Guide.html
Cisco 2900 Series ISRs
Table 5 lists the slots and ports available on Cisco 2900 series routers.
To view the installation guide, see the following URL
http://www.cisco.com/en/US/docs/routers/access/2900/hardware/installation/guide/Hardware_Installati
on_Guide.html
Table 4 Cisco 3900 Series Routers
Router EHWIC SM
Dbl-Wide
SM ISM PVDM3 CF
GE (RJ-45)/
SFP ports SPE
Cisco 39454 41 14 23
1
1. One RJ-45 GE + two combo GE/SFPs.
1
Cisco 3945E 3 4 1 0 3 2 4
2
2. Four RJ-45 GE, or three RJ-45 GE + one combo GE/SFP, or two RJ-45 GE + two combo GE/SFP.
1
Cisco 39254 21 14 23
3
3. One RJ-45 GE + two combo GE/SFPs, or three RJ-45 GEs.
1
Cisco 3925E 3 2 1 0 3 2 4
4
4. Four RJ-45 GE, or three RJ-45 GE + one combo GE/SFP, or two RJ-45 GE + two combo GE/SFP.
1
Table 5 Cisco 2900 Series Routers
Router EHWIC SM
Dbl-Wide
SM ISM PVDM3 CF
GE (RJ-45)
ports
GE (RJ-45)/
SFP ports
Cisco 29514 22 13 22 1
Cisco 29214 11 13 22 1
Cisco 29114 11 12 23 0
Cisco 29014 00 12 23 0

Cisco 2901 Specifications

General

Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Ethernet LAN	Yes
Cabling technology	10/100/1000BASE-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
Ethernet LAN (RJ-45) ports	2
Firewall security	Cisco IOS
Input current	1.5 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	40 W
Product color	Black
Rack capacity	1U
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Flash memory	256 MB
Internal memory	512 MB
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	439.4 mm
Width	438.2 mm
Height	44.5 mm
Weight	6100 g
