Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet Virtual Connection Bridge Domain
Connectivity Fault Management (CFM) over EVC BD
SUMMARY STEPS
Step 1 enable
Step 2 configure terminal
Step 3 ethernet cfm domain domain-name level level-id [direction outward]
Step 4 mep archive-hold-time minutes
Step 5 exit
Step 6 ethernet cfm global
Step 7 ethernet cfm ieee
Step 8 ethernet cfm traceroute cache
Step 9 ethernet cfm traceroute cache size entries
Step 10 ethernet cfm traceroute cache hold-time minutes
Step 11 snmp-server enable traps ethernet cfm cc [mep-up] [mep-down] [config] [loop] [cross-connect]
Step 12 snmp-server enable traps ethernet cfm crosscheck [mep-unknown] [mep-missing] [service-up]
Step 13 end
DETAILED STEPS
Command Purpose
Step 1
enable
Example:
Router> enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.
Step 3
ethernet cfm domain domain-name level
level-id [direction outward]
Example:
Router(config)# ethernet cfm domain
Customer level 7 direction outward
Defines an outward CFM maintenance domain at a
particular maintenance level and enters Ethernet CFM
configuration mode.
Step 4
mep archive-hold-time minutes
Example:
Router(config-ecfm)# mep
archive-hold-time 60
Sets the amount of time that data from a missing MEP is
kept in the continuity check database or that entries are
held in the error database before they are purged.
Step 5
exit
Example:
Router(config-ecfm)# exit
Returns the device to global configuration mode.

Cisco 2901 Specifications

General

Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Ethernet LAN	Yes
Cabling technology	10/100/1000BASE-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
Ethernet LAN (RJ-45) ports	2
Firewall security	Cisco IOS
Input current	1.5 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	40 W
Product color	Black
Rack capacity	1U
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Flash memory	256 MB
Internal memory	512 MB
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	439.4 mm
Width	438.2 mm
Height	44.5 mm
Weight	6100 g
