Cisco 2911 Configuration Guide

94
Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring EtherChannel
Restrictions and Guidelines for EtherChannel Feature
Configuring EtherChannel.
Perform these steps to configure the EtherChannel feature on Cisco 1900, 2900 and 3900 series ISRs.
SUMMARY STEPS
1. configure terminal
2. interface port-channel number
3. ip address ip-address mask
4. end
5. interface range type number - number
6. channel-group number
7. end
DETAILED STEPS
Command Purpose
Step 1
configure terminal
Example:
Router# configure terminal
Enters global configuration mode.
Step 2
interface port-channel number
Example:
Router(config)# interface port-channel 1
Specify the EtherChannel (port channel) logical
interface, and enter interface configuration mode.
Step 3
ip address ip-address mask
Example:
Router(config-if)# ip address 10.0.0.1
255.255.255.0
Assign an IP address and subnet mask to the
EtherChannel.
Step 4
end
Example:
Router(config-if)# end
Returns to privileged EXEC mode.
Step 5
interface range type number - number
Example:
Router(config)# interface range
gigabitEthernet 0/0-1
Configures the interface range for the
EtherChannel.

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
