Chapter Configuring Radio Settings
Configuring MCS Rates
MCS rates are configured using the speed command. The following example shows a speed setting for
an 802.11g/n 2.4-GHz radio:
interface Dot11Radio0
no ip address
no ip route-cache
!
ssid 800test
!
speed basic-1.0 2.0 5.5 11.0 6.0 9.0 12.0 18.0 24.0 36.0 48.0 54.0 m0. m1. m2. m3. m4. m8.
m9. m10. m11. m12. m13. m14. m15.
Table 1 Data Rates Based on MCS Settings, Guard Interval, and Channel Width
MCS Index Guard Interval = 800 ns Guard Interval = 400 ns
20-MHz Channel
Width Data Rate
(Mb/s)
40-MHz Channel
Width Data Rate
(Mb/s)
20-MHz Channel
Width Data Rate
(Mb/s)
40-MHz Channel
Width Data Rate
(Mb/s)
0 6.5 13.5 7 2/9 15
1 132714 4/930
2 19.5 40.5 21 2/3 45
3 265428 8/960
4 398143 1/390
5 52 109 57 5/9 120
6 58.5 121.5 65 135
7 65 135 72 2/9 152.5
8 132714 4/930
9 265428 8/960
10 39 81 43 1/3 90
11 52 108 57 7/9 120
12 78 162 86 2/3 180
13 104 216 115 5/9 240
14 117 243 130 270
15 130 270 144 4/9 300
The legacy rates are as follows:
5 GHz: 6, 9, 12, 18, 24, 36, 48, and 54 Mb/s
2.4 GHz: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mb/s

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
