Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide

Chapter Configuring Ethernet Virtual Connection Bridge Domain

Connectivity Fault Management (CFM) over EVC BD

IEEE CFM is an end-to-end per-service Ethernet-layer Operations, Administration, and Maintenance

(OAM) protocol. CFM includes proactive connectivity monitoring, fault verification, and fault isolation

for large Ethernet metropolitan-area networks (MANs) and WANs.

CFM over EVC BD (Up mep) and CFM over EVC BD (Down mep) features are supported on CFM over

EVC BD.

CFM over Xconnect (Up mep) and CFM over Xconnect (Down mep) features are not supported on CFM

over EVC BD.

The benefits of Ethernet CFM are:

• End-to-end service-level OAM technology

• Reduced operating expense for service provider Ethernet networks

• Competitive advantage for service providers

Note This feature is supported only if you have purchased the appxk9 licensing package. CFM over EVC BD

is available only on the Cisco 890 series ISR and ISRG2 platforms. For more information about

managing software activation licenses on the Cisco ISR and Cisco ISR G2 platforms, see

http://www.cisco.com/en/US/docs/routers/access/sw_activation/SA_on_ISR.html.

Restrictions for Configuring Ethernet CFM

• A specific domain must be configured. If it is not, an error message is displayed.

• Multiple domains (different domain names) having the same maintenance level can be configured.

However, associating a single domain name with multiple maintenance levels is not permitted.

Configuring Ethernet CFM

• Provisioning the Network (CE-A), page 68

• Provisioning the Network (CE-B), page 70

• Provisioning Service (CE-A), page 73

• Provisioning Service (CE-B), page 76

• Configuring and Enabling the Cross-Check Function (CE-A), page 78

• Configuring and Enabling the Cross-Check Function (CE-B), page 80

• Configuration Examples for Configuring Ethernet CFM for the Cisco ISR G2 Routers, page 81

Provisioning the Network (CE-A)

Complete these steps to configure provisioning the network (CE-A):

SUMMARY STEPS

Step 1 enable

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1
