Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet Virtual Connection Bridge Domain
Connectivity Fault Management (CFM) over EVC BD
Configuring and Enabling the Cross-Check Function (CE-A)
Perform this task to configure and enable cross-checking for a down MEP. This task requires you to
configure and enable cross-checking on two devices. This task is optional.
Step 12
ethernet cfm ieee
Example:
Router(config)# ethernet cfm ieee
Enables the CFM IEEE version of CFM.
• This command is automatically issued when the
ethernet cfm global command is issued.
Step 13
ethernet cfm traceroute cache
Example:
Router(config)# ethernet cfm
traceroute cache
Enables caching of CFM data learned through traceroute
messages.
Step 14
ethernet cfm traceroute cache size
entries
Example:
Router(config)# ethernet cfm
traceroute cache size 200
Sets the maximum size for the CFM traceroute cache
table.
Step 15
ethernet cfm traceroute cache
hold-time minutes
Example:
Router(config)# ethernet cfm
traceroute cache hold-time 60
Sets the amount of time that CFM traceroute cache entries
are retained.
Step 16
interface type number
Example:
Router(config)# interface ethernet
0/3
Specifies an interface and enters interface configuration
mode.
Step 17
ethernet cfm mep level level-id
[inward | outward domain domain-name]
mpid id vlan{any | vlan-id | ,
vlan-id | vlan-id - vlan-id | vlan-id
- vlan-id}
Example:
Router(config-if)# ethernet cfm mep
level 7 outward domain Customer mpid
701 vlan 100
Provisions an interface as a domain boundary.
Step 18
end
Example:
Router(config-if)# end
Router#
Returns the router to the privileged EXEC mode.
Command Purpose

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
