Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet Virtual Connection Bridge Domain
Connectivity Fault Management (CFM) over EVC BD
SUMMARY STEPS
Step 1 enable
Step 2 configure terminal
Step 3 ethernet cfm domain domain-name level level-id
Step 4 mep mpid mpid
Step 5 exit
Step 6 ethernet cfm mep crosscheck start-delay delay
Step 7 exit
Step 8 ethernet cfm mep crosscheck {enable | disable} domain domain-name] {port | vlan {vlan-id | vlan-id
- vlan-id | , vlan-id - vlan-id}}
DETAILED STEPS
Command Purpose
Step 1
enable
Example:
Router>enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.
Step 3
ethernet cfm domain domain-name level
level-id
Example:
Router(config)# ethernet cfm domain
Customer level 7
Defines a CFM maintenance domain at a specified level
and enters Ethernet CFM configuration mode.
Step 4
mep mpid mpid
Example:
Router(config-ecfm)# mep mpid 702
Statically defines the MEPs within a maintenance
association.
Step 5
exit
Example:
Router(config-ecfm)# exit
Returns the device to global configuration mode.
Step 6
ethernet cfm mep crosscheck
start-delay delay
Example:
Router(config)# ethernet cfm mep
crosscheck start-delay 60
Configures the maximum amount of time that the device
waits for remote MEPs to come up before the cross-check
operation is started.

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
