Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Upgrading the Cisco IOS Software
How to Upgrade the IOS Image on the Access Point
description Service module interface to manage the embedded AP
ip address 10.0.0.1 255.0.0.0
arp timeout 0
!
interface GigabitEthernet0/1
no ip address
shutdown
duplex auto
speed auto
!
interface Vlan1
ip address 192.168.10.1 255.255.255.0
!
ip forward-protocol nd
ip route 0.0.0.0 0.0.0.0 GigabitEthernet0/0
!
no ip http server
Upgrading the IOS Image on the Access Point
Follow the image upgrade instructions at Cisco.com using the IOS CLI,
http://www.cisco.com/en/US/docs/wireless/access_point/12.3_8_JA/configuration/guide/
s38mfw.html#wp1035609.
Note If the access point enters Bootloader mode, manually configure the IP address, default router, netmask,
and default gateway to upgrade the IOS image.
Note The IP address must be assigned to the same subnet as the VLAN1 interface on the router. Here is an
example configuration.
Example
ap: set
CONTROLLER_TYPE=0x05A4
DEFAULT_ROUTER=192.168.10.1
ENABLE_BREAK=yes
IOS_STATIC_DEFAULT_GATEWAY=192.168.10.1
IP_ADDR=192.168.10.2
MANUAL_BOOT=yes
NETMASK=255.255.255.0
PEP_PRODUCT_ID=AP801AGN-A-K9
PRODUCT_MODEL_NUM=AP801AGN-A-K9
TOP_ASSY_SERIAL_NUM=FHKTESTTEST
ap: copy tftp://223.255.254.254/saek/ap801-k9w7-tar.124-10b.JDA flash0:
ap801-k9w7-tar.124-10b.JDA

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
