Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Security Features
Configuring VPN
Configure the IPSec Crypto Method and Parameters
A dynamic crypto map policy processes negotiation requests for new security associations from remote
IPSec peers, even if the router does not know all the crypto map parameters (for example, IP address).
To configure the IPSec crypto method, follow these steps, beginning in global configuration mode.
SUMMARY STEPS
1. crypto dynamic-map dynamic-map-name dynamic-seq-num
2. set transform-set transform-set-name [transform-set-name2...transform-set-name6]
3. reverse-route
4. exit
5. crypto map map-name seq-num [ipsec-isakmp] [dynamic dynamic-map-name] [discover]
[profile profile-name]
DETAILED STEPS
Command or Action Purpose
Step 1
crypto dynamic-map dynamic-map-name
dynamic-seq-num
Example:
Router(config)# crypto dynamic-map dynmap 1
Router(config-crypto-map)#
Creates a dynamic crypto map entry and enters
crypto map configuration mode.
See Cisco IOS Security Command Reference for
more detail about this command.
Step 2
set transform-set transform-set-name
[transform-set-name2...transform-set-name6]
Example:
Router(config-crypto-map)# set
transform-set vpn1
Router(config-crypto-map)#
Specifies which transform sets can be used with
the crypto map entry.
Step 3
reverse-route
Example:
Router(config-crypto-map)# reverse-route
Router(config-crypto-map)#
Creates source proxy information for the crypto
map entry.
See Cisco IOS Security Command Reference for
details.

Cisco 2921 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Product color	Black
Rack capacity	2U
USB version	2.0
RS-232 ports	1
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
Firewall security	Cisco IOS
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	469.9 mm
Width	438.2 mm
Height	88.9 mm
Weight	13200 g
