Cisco 2921 User Manual

156
Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Identity Features on Layer 3 Interface
Authentication Methods
SUMMARY STEPS
1. enable
2. configure terminal
3. interface gigabitethernet slot / port
4. authentication port-control auto
5. dot1x pae authenticator
6. end
DETAILED STEPS
Verifying the IEEE 802.1X
Use the show authentication sessions command to verify the configuration:
c1921#show authentication sessions
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Enables privileged EXEC mode. Enter your
password if prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters global configuration mode.
Step 3
interface gigabitethernet slot/port
Example:
Router(config)# interface gigabitethernet
0/0
Enters interface configuration mode.
Step 4
authentication port-control auto
Example:
Router(config-if)# authentication
port-control auto
Enables the manual control of the port
authorization state.
Step 5
dot1x pae authenticator
Example:
Router(config-if)#dot1x pae authenticator
Configures the port as an IEEE 802.1x Port Access
Entity (PAE) authenticator.
Step 6
end
Example:
Router(config-if)# end
Router#
Returns to privileged EXEC mode.

Cisco 2921 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Product color	Black
Rack capacity	2U
USB version	2.0
RS-232 ports	1
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
Firewall security	Cisco IOS
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	469.9 mm
Width	438.2 mm
Height	88.9 mm
Weight	13200 g
