Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet CFM and Y.1731 Performance Monitoring on Layer 3 Interfaces
CFM Support on Routed Port and Port MEP
DETAILED STEPS
Command Purpose
Step 1
enable
Example:
Router>enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router#configure terminal
Enters the global configuration mode.
Step 3
ethernet cfm ieee
Example:
Router(config)#ethernet cfm ieee
Enables the IEEE version of CFM.
Step 4
ethernet cfm global
Example:
Router(config)#ethernet cfm global
Enables CFM processing globally on the router.
Step 5
ethernet cfm domain domain-name level
0 to 7
Example:
Router(config-ecfm)#ethernet cfm
domain customer level 7
Defines a CFM maintenance domain at a specified level,
and enters Ethernet CFM configuration mode.
level can be any value from 0 to 7.
Step 6
service service-name vlan vlan-id
inner-vlan inner vlan-id direction
down
Example:
Router(config-ecfm)#service
customer1101 vlan 100 inner-vlan 30
direction down
Enters the CFM service configuration mode.
The following are the parameters:
• vlan—Specifies the VLAN.
• inner-vlan—The inner-vlan keyword and the inner
vlan-id argument specify the VLAN tag for
double-tagged packets.
Step 7
continuity-check
Example:
Router(config-ecfm-srv)#continuity-ch
eck
Enables sending continuity check messages.
Step 8
interface gigabitethernet slot/port
Example:
Router(config-ecfm-srv)#interface
gigabitethernet 0/2
Specifies an interface and enters the interface
configuration mode.

Cisco 2921 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Product color	Black
Rack capacity	2U
USB version	2.0
RS-232 ports	1
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
Firewall security	Cisco IOS
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	469.9 mm
Width	438.2 mm
Height	88.9 mm
Weight	13200 g
