Cisco 2960-C User Manual

2-12
Catalyst 3560-C and 2960-C Switch Hardware Installation Guide
OL-23803-02
Chapter 2 Switch Installation
Mounting the Switch
Figure 2-6 Installing the Mounting Screws on the Wall
Figure 2-7 Installing the Switch on a Wall
Step 8
Place the switch onto the mounting screws, and slide it down until it locks in place. See Figure 2-7.
CABLE SIDE ENTRY
THIS SIDE AWAY FROM
MOUNTING SURFACE
2
3
2
2
1
157828
R
E
SE
T
A
U
X
5
3
V
, 1.
5
A
3
1
2
2
2
208926

Cisco 2960-C Specifications

General

Switching Capacity	16 Gbps
Forwarding Rate	6.5 Mpps
MAC Address Table Size	8, 000 entries
RAM	128 MB
Flash Memory	64 MB
Stacking	Not supported
Ports	8 x 10/100 Fast Ethernet
Uplink Interfaces	1 x dual-purpose (10/100/1000 or SFP)
PoE	No PoE
Storage Temperature	-20°C to 65°C
Relative Humidity	10% to 85% non-condensing
Operating Temperature	32°F to 113°F (0°C to 45°C)
