Cisco 2960-C User Manual

2-28
Catalyst 3560-C and 2960-C Switch Hardware Installation Guide
OL-23803-02
Chapter 2 Switch Installation
Installing the Cable Guard (Optional)
Installing the Cable Guard (Optional)
The cable guard prevents tampering with the cables after the cables are installed. The cable guard
(CMP-CBLE-GRD=) is not included with the switch, but you can order it from your Cisco
representative.
Note You can use the cable guard when the switch is mounted on a desk, under a desk, or on a wall.
The cable guard is shipped with these items:
• Two 0.5 in. (12.7 mm) number-8 Phillips wood screws
• Two number-10 Phillips pan-head screws
• Two washers
Step 1 (Optional) Attach the supplied washers before you install the cable guard. See Figure 2-28.
Note This is only required if you are not installing the wall-mount brackets.
Figure 2-28 Using the Washer
1 Washer
MODE
CON SO L E
1
2
Ser i es
PD
P
OW
ER
O
V
ER
E
T
H
ERNET
12345678
PD
SPD
Po E
DPLX
STAT
SYST
330047
1

Cisco 2960-C Specifications

General

Switching Capacity	16 Gbps
Forwarding Rate	6.5 Mpps
MAC Address Table Size	8, 000 entries
RAM	128 MB
Flash Memory	64 MB
Stacking	Not supported
Ports	8 x 10/100 Fast Ethernet
Uplink Interfaces	1 x dual-purpose (10/100/1000 or SFP)
PoE	No PoE
Storage Temperature	-20°C to 65°C
Relative Humidity	10% to 85% non-condensing
Operating Temperature	32°F to 113°F (0°C to 45°C)
