Cisco 2960-C User Manual

2-27
Catalyst 3560-C and 2960-C Switch Hardware Installation Guide
OL-23803-02
Chapter 2 Switch Installation
Installing the Power Cord Retainer (Optional)
Figure 2-26 Sleeve Around the Power Cord
Step 6
Secure the AC power cord by pressing on the retainer. See Figure 2-27.
Figure 2-27 Securing the Power Cord in the Retainer
1 Sleeve for thin power cords 2 AC power cord
1
2
1
208987
208988

Cisco 2960-C Specifications

General

Switching Capacity	16 Gbps
Forwarding Rate	6.5 Mpps
MAC Address Table Size	8, 000 entries
RAM	128 MB
Flash Memory	64 MB
Stacking	Not supported
Ports	8 x 10/100 Fast Ethernet
Uplink Interfaces	1 x dual-purpose (10/100/1000 or SFP)
PoE	No PoE
Storage Temperature	-20°C to 65°C
Relative Humidity	10% to 85% non-condensing
Operating Temperature	32°F to 113°F (0°C to 45°C)
