Cisco 2960-C User Manual

2-26
Catalyst 3560-C and 2960-C Switch Hardware Installation Guide
OL-23803-02
Chapter 2 Switch Installation
Installing the Power Cord Retainer (Optional)
Step 3 Slide the retainer through the first latch. See Figure 2-24.
Figure 2-24 Sliding the Retainer Through the Latch
Step 4
Slide the retainer through the other latches to lock it. See Figure 2-25.
Figure 2-25 Locking the Retainer
(
Step 5 (Optional) Use the small sleeve for thin power cords. Use the small sleeve to provide greater stability for
thin cords. Detach the sleeve, and slide it over the power cord. See Figure 2-26.
1 AC power cord 3 Latch
2 Smaller sleeve for thin power cords
RESET
1
2
3
208985
1 AC power cord 3 Latches
2 Sleeve for thin power cords
RESET
1
2
3
208986

Cisco 2960-C Specifications

General

Switching Capacity	16 Gbps
Forwarding Rate	6.5 Mpps
MAC Address Table Size	8, 000 entries
RAM	128 MB
Flash Memory	64 MB
Stacking	Not supported
Ports	8 x 10/100 Fast Ethernet
Uplink Interfaces	1 x dual-purpose (10/100/1000 or SFP)
PoE	No PoE
Storage Temperature	-20°C to 65°C
Relative Humidity	10% to 85% non-condensing
Operating Temperature	32°F to 113°F (0°C to 45°C)
