Cisco 2960-C User Manual

2-22
Catalyst 3560-C and 2960-C Switch Hardware Installation Guide
OL-23803-02
Chapter 2 Switch Installation
Mounting the Switch
Figure 2-19 Mounting the Switch on a DIN Rail
Step 2
Rotate the switch down toward the DIN rail until the release tabs on the DIN rail mount clicks.
Step 3 Lift lightly on the bottom of the switch to ensure that it is firmly locked in place.
After you install the switch, see the “After Installing the Switch” section on page 2-31 for information
about the switch configuration.
1 Switch
1
344214
RESET
AUX 53V , 1.5A

Cisco 2960-C Specifications

General

Switching Capacity	16 Gbps
Forwarding Rate	6.5 Mpps
MAC Address Table Size	8, 000 entries
RAM	128 MB
Flash Memory	64 MB
Stacking	Not supported
Ports	8 x 10/100 Fast Ethernet
Uplink Interfaces	1 x dual-purpose (10/100/1000 or SFP)
PoE	No PoE
Storage Temperature	-20°C to 65°C
Relative Humidity	10% to 85% non-condensing
Operating Temperature	32°F to 113°F (0°C to 45°C)
