Jumper Settings
Token
Ring
Serial
Console/AUX
port
port ports
Using
the orientation
of
Figure
5-7 for the model
3202 default
jumper locations
note that Wi
ships
with its left
two
pins jumpered
together
At location
W3
the two left
pins
are
jumpered
to
permit
writing
to
Flash
memory
or the two
right pins
are
jumpered
to disable
writing
to Flash
memoly
At
location
W4
the
jumper
corresponds
to the size of boot
ROM
memory
as shown
on
the ROM labels
LED
Figure
5-1 Model 3202
System
Card
Layout
5-10 Cisco
3000 Hardware Installation and Maintenance
