Figure 15: SFP Transceiver
Bail clasp2Dust plug1
Transmit optical bore4Receive optical bore3
Safety Warnings
Take note of the following warnings:
Statement 1055—Class 1/1M Laser
Invisible laser radiation is present. Do not expose to users of telescopic optics. This applies to Class 1/1M
laser products.
Warning
Statement 1056—Unterminated Fiber Cable
Invisible laser radiation may be emitted from the end of the unterminated fiber cable or connector. Do
not view directly with optical instruments. Viewing the laser output with certain optical instruments, for
example, eye loupes, magnifiers, and microscopes, within a distance of 100 mm, may pose an eye hazard.
Warning
Statement 1057—Hazardous Radiation Exposure
Use of controls, adjustments, or performance of procedures other than those specified may result in
hazardous radiation exposure.
Warning
Cisco Secure Firewall 3100 Series Hardware Installation Guide
29
