Rack-Mount the Chassis Using Brackets
This procedure describes how to install the Secure Firewall 3100 in a rack using the rack-mount brackets. It
also describes how to install the optional cable management brackets. See Product ID Numbers, on page 33
for a list of the PIDs associated with rack-mounting the chassis.
The rack is a standard Electronic Industries Association (EIA) rack. It is a 4-post-EIA-310-D, which is the
current revision as specified by EIA. The vertical hole spacing alternates at .50 inches (12.70 mm) to .625
inches (15.90 mm) to .625 inches (15.90 mm) and repeats. The start and stop space is in the middle of the
.50-inch holes. The horizontal spacing is 18.312 inches (465.1 mm), and the rack opening is specified as a
minimum of 17.75 inches (450 mm).
You need the following to install the Secure Firewall 3100 in a rack:
• Phillips screwdriver
• Two rack-mount brackets (part number 700-127244-01) with six 8-32 x 0.375 inch screws (part number
48-2286-01)
• Rack-mount screws:
• Four 12-24 x 0.75 inch Phillips screws (part number 648-0440-01) for securing the chassis to your
rack
• Four 10-32 x 0.75 inch Phillips screws (part number 48-0441-01) for securing the chassis to your
rack
• (Optional) Cable management bracket kit (part number 69-100376-01):
• Two cable management brackets (part number 700-106377-01)
• Four 8-32 x 0.375 inch Phillips screws (part number 48-2696-01)
Step 1 Attach a rack-mount bracket to each side of the chassis using the six 8-32 x 0.375 inch Phillips screws (three per side).
