Cisco 3100 Series User Manual

CHAPTER 4
Installation, Maintenance, and Upgrade
• Install, Remove, and Replace the Network Module, on page 65
• Remove and Replace the SSD, on page 67
• Remove and Replace the Dual Fan Module, on page 70
• Remove and Replace the Power Supply Module, on page 71
• Connect the DC Power Supply Module, on page 74
• Secure the Power Cord on the Power Supply Module, on page 76
Install, Remove, and Replace the Network Module
You can remove and replace the network module (NM-2) in the Secure Firewall 3100. Hot-swapping of
identical modules is supported, but if you replace a network module with another type, you must reboot the
system so that the new network module is recognized.
See the configuration guide for your operating system for the procedure for managing network modules.
You can install all supported network modules in all Secure Firewall 3100 models, but the 40-Gb network
module (FPR-X-NM-4X40G) and the 1/10/25-Gb network module (FPR-X-NM-8X25G) are only recognized
when installed in the 3130 and 3140. The software does not support these network modules for the 3105,
3110, and 3120.
Caution
This procedure describes how to install a network module into an empty slot that has never contained a network
module, and how to remove an installed network module and replace it with another network module.
Safety Warnings
Take note of the following warnings:
Statement 1030—Equipment Installation
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
Cisco Secure Firewall 3100 Series Hardware Installation Guide
65
