Cisco 3100 Series User Manual

31403130312031103105Feature
Eight 1/10/25-Gb SFP ports
Four 40-Gb QSFP ports
Network module
ports
One
Hot-swapping of identical modules is supported, but if you replace a network
module with another type, you must reboot the system so that the new network
module is recognized.
Note
Network module
slots
• 8-port 1Gb/10Gb/25Gb SFP+
(FPR3K-XNM-8X25G)
• 8-port 1Gb/10Gb SFP+
(FPR3K-XNM-8X10G)
• 4-port 40-Gb QSFP+
(FPR3K-XNM-4X40G)
• 6-port 1-Gb SFP SX
multimode hardware
bypass(FPR3K-XNM-6X1SXF)
• 6-port 10-Gb SFP SR
multimode hardware bypass
(FPR3K-XNM-6X10SRF)
• 6-port 10-Gb SFP LR single
mode hardware bypass
(FPR3K-XNM-6X10LRF)
• 6-port 25-Gb SFP SR
multimode hardware bypass
(FPR3K-XNM-6X25SRF)
• 6-port 25-Gb SFP LR single
mode hardware bypass
(FPR3K-XNM-6X25LRF)
• 8-port 10/100/1000Base-T
hardware bypass
(FPR3K-XNM-8X1GF)
• 8-port 1Gb/10Gb SFP+ (FPR3K-XNM-8X10G)
• 6-port 1-Gb SFP SX multimode hardware bypass
(FPR3K-XNM-6X1SXF)
• 6-port 10-Gb SFP SR multimode hardware
bypass (FPR3K-XNM-6X10SRF)
• 6-port 10-Gb SFP LR single mode hardware
bypass (FPR3K-XNM-6X10LRF)
• 6-port 25-Gb SFP SR multimode hardware
bypass (FPR3K-XNM-6X25SRF)
• 6-port 25-Gb SFP LR single mode hardware
bypass (FPR3K-XNM-6X25LRF)
• 8-port 10/100/1000Base-T hardware bypass
(FPR3K-XNM-8X1GF)
Network
modules
Two power supply slots
Ships with two 400-W AC power
supply modules
Hot-swappable
Two power supply slots
Ships with one 400-W AC power supply module
Hot-swappable
AC power
supply
Yes (optional)
Hot-swappable
DC power
supply
Cisco Secure Firewall 3100 Series Hardware Installation Guide
3
Overview
Features
